Mold Shop
Our main custom mold shop is 15,750 sq ft, temperature controlled facility built in 1999. At this time it has 13 CNC which includes the 5 axis, 2 Overhead cranes, Gundrill, Boring Mill and new fork truck. Most of our CNC machines are installed with a probe system for dimension checks and accuracy. American Tool has large CNCs to fit large machining needs. ATE specializes in large, deep, complex, intricate, and precise molds. We also offer mold repair and mold revisions.
HAAS UMC 1000ss
Travels- X AXIS - 40" Y AXIS - 25" Z AXIS - 25"
C AXIS ROTATION - 360° ROTATION
B AXIS TILT - (-35°) to (+110°)
PLATTER DIAMETER - 25"
Travels: X-106.3”, Y-86.6”, Z-39.4”
(C axis pitch +/-110 degrees ) – (A axis roll +/200 degrees)
Renshaw Probing – 24,000 RPM
Travels: X -86”, Y- 160”, Z- 38”
#50 Taper- 8,000 RPM
Coolant thru spindle and Renishaw Probing
Travels: X- 80”, Y- 39”, Z-47”
#50 Taper- 8,000 RPM
Coolant thru spindle and Renishaw Probing
Travels: X-50”, Y- 20”, Z-25”
#40 Taper – 10,000 RPM
Coolant thru spindle and Renshaw Probing
Travels: X-50”, Y- 20”, Z -25”
HAAS connect- 12,000 RPM
Coolant thru spindle and Renshaw Probing
CNC-2015 HAAS VF-9s
Travels: X-80”, Y-40”, Z- 30”
#40 Taper - 12,000RPM
Coolant thru spindle and Renshaw Probing.
CNC-2014 HAAS VF-9
Travels: X-80”, Y-40”, Z- 30”
#40 Taper - 10,000RPM
Coolant thru spindle and Renshaw Probing
Travel: X- 50”, Y-30”, Z-28”
#50 Taper - 6,000 RPM
Travels- X-86”, Y -42”, Z- 37”
#50 Taper- 6,000 RPM
Max Drill depth 96” x 1.5” DIA. Hole
Travels- X-21”, Z- 26”
3,400 RPM
Automatic Tool Presetter Programmable Tailstock – Renishaw Probe
